Programming

overarching concepts

• computing/software is lifelong learning!
• do as little as possible "interactively", so it is repeatable
• less is more (to a point) - don't repeat work, make the tool better and reusable
• all software should be written as if someone else will use it: document and share

philosophy

From Quora, response to a question about value of formal training in programming vs. picking it up on your own:

Upvoted by Alagunarayanan Narayanan, Software Engineer " I was a self-taught programmer for about 4 years, before taking a few courses as extras in my EE degree. I am now pursuing a MSc in CS. So my answer is mostly observations on how I do things differently now compared to how I did them before.

Architecting projects is a big thing. Given a list of things the software is required to do, how would you lay out your program so that it -

1. Does what it's supposed to do
2. Is maintainable
3. Is easily understandable for other people (and yourself in a few months)
4. Is easily extensible if the requirements change (as they always do)
5. Uses the most suitable design patterns to make the code intuitive

Usually self-taught programmers do 1., but don't pay nearly as much attention, or only pay lip service to the other points. I thought I knew about all those other points, but as I found out later, I really had no idea.

Another big difference is how much trial and error. I did a lot more trial and error back in the days, because I didn't have good understanding about how "the whole stack" works. I used a lot of things without bothering to truly understand how they work under the hood.

Nowadays I almost don't do any trial and error at all. I think through everything, and most things I actually start coding actually work on the first try (not counting typos, etc). I know exactly how memory management works all the way from kernel to malloc. I know how schedulers work (having written a few for a course), and I know what the synchronization mechanisms are, the pros and cons of each, the usual patterns in which they are used, as well as how they are actually implemented on the instruction level. As a self-taught programmer, I knew how to use mutexes and that's about it. As it turned out, I actually (poorly) reinvented a few of the other standard mechanisms.

Self-taught programmers are also usually not used to reading a lot of code written by other people, which is a very important skill when working in teams.

Knowledge of the existing algorithms is another one.

When a non-trivial problem is encountered, a bad programmer dives head first into coding a solution. A better programmer looks for solutions, and tries them out. A good programmer looks for solutions, analyzes them for time and space complexity as well as other constraints, and implements the most likely one.

Most self-taught programmers start coding too early.

And like you said, things like AI and ML. Most self-taught programmers never learn those things, because usually they only learn things they need, and if you don't know AI and ML, they won't seem like possible solutions to your problems, and you'll never think about learning them. It's a chicken and eggs problem. Self-taught programmers often don't know what they don't know. One nice thing about doing a degree is that it almost forcefully introduces you to everything, so by the time you are done, at least you know what you don't know."

languages

compiled vs. non-compiled. Distinction perhaps less clear now than it was in the past. But key point is that, for certain applications, you may want to consider execution time.

open-source vs. proprietary

Languages: commonly used in astronomy: Python, C, C++, Fortran, IDL, MATLAB. Many other languages exist: C++, C#, Java, Javscript, etc. etc.

Fortran: historical language of choice of scientific computing in mid/late 20th century. Many codes developed that are still in existence/development (e.g., Anatoly's N-body and Hydro codes, synthetic spectra generation MOOG and TURBOSPEC, stellar evolution MESA, Chris' codes, others...). In addition, many routines coded for fast operation available, e.g. LAPACK. Various versions of fortran: F66, F77, F90/F95

C: foundational language for computer science. Some astronomical routines: SAO WCSTOOLS for astronomical coordinate system routines, HSTPHOT/DOLPHOT for HST photometry, SLALIB for more astronomical coordinate routines, others....

Python: major push in current astronomical software development. astropy

IDL: historical very close connection to astronomy, with much development at LASP and Goddard Space Flight Center in the public domain. Marketed through RSI, then ITT, now Exelis, as a licensed software product. Originally written in C? Major astronomical software infrastructure exists in IDL, e.g. for planetary and solar astrophysics (perhaps because of NASA / GSFC). Astronomy users library. Major component of SDSS software, although modern evolution away from it.

Getting started

see programming reference table

Let's do a simple program in all languages.

Getting started with Fortran

Basic program structure:

1. program statement
2. variable declarations
3. program statements
4. end

Basic language:

• f77 starts in column 7, f95 can start in column 1.
• Comments: f95: exclamation (!), f77: C in column 1
• line continuation: f95 end line with &

Compiling and running programs: compiling, linking, makefile, BINDIR, path

Getting started with C

Basic program structure:

1. #include files
2. int main() {
3. variable declarations
4. program statements
5. }

Comments: double-slash (//), or embed between /* and */

Compiling and running programs: compiling, linking, makefile, BINDIR, path

Introduction to makefiles

Introduction to makefiles (see, e.g., the GNU documentations or someone else's explanations. Explicit commands, variable filenames, rules.

Defining rules, e.g. Latex into PDF, etc Standard rules.

Standard targets: install, objs, etc.

Getting started with Python

Using command interpreter: python vs ipython (use ipython so you can access its features!)

Using programs: running interactively, running as a script, running as an executable, using %run with ipython

PATH and PYTHONPATH environment variables: executables are searched for in PATH, Python imports are searched for in PYTHONPATH and system-installed libraries.

Comments: hash (#).

Python useful references: Python tutorial python4astronomers

Getting started with IDL

are searched for in PATH, Python imports are searched for in PYTHONPATH and system-installed libraries. Using command interpreter.

Using programs: running a script using @, running a program using .run, idl -e

IDL_PATH

Comments: semicolon (;)

Simple makefile

Simple makefile (note that indents must be TABs):

hello_f:
    f95 -c hello_f.f95
    f95 -o hello_f hello_o

hello_c:
    cc  -c hello_c.c
    cc  -o hello_c hello_c.o

run:
    hello_f
    hello_c
    hello.py
    idl -e ".run hello.py"

Basic programming

see programming reference table for syntactical details in each language.

program construction

• basic program structure

• comments and good commenting practice

• line continuation

Variables

• variables and memory, declaration and initialization.

• Basic variable types: integer, float, string. Determining variable type in Python (type) and IDL (size,/type).

• Type conversion

• arrays and array operation: order of elements in multidimensional array (column-major vs row-major). Array as a continuous stretch in memory.

• pointers: addresses vs values

• dynamic memory allocation: allocate and malloc

• multitype collections: structures (derived data types). Arrays of structures. Python lists, tuples, dictionaries, and structured arrays

Operators

• mathematical

• string

• Bitmasks and logical operators.

• Vector operators.

Control statments

• conditional: if/then/else

• control loops: for and while

Input and output (I/O)

• I/O : formatted output.

• I/O : simple input. Reading unknown length files in Fortran and C

• I/O : higher level routines: Python astropy.io.ascii, numpy.loadtxt (but note this only reads a single data type into an array, rather than into a structured array, as astropy.io.ascii does). IDL read_ascii

• Binary data: note issues of N-dimensional array unwrapping, byte order
  • Fortran: OPEN(lun,file,FORM='binary'), READ/WRITE without format statements
  • C: fopen(), fread(), fwrite()
  • Python: open files in binary mode (rb, wb), struct.pack and struct.unpack to convert to binary data
  • IDL: READ_BINARY

• FITS files
  • image data: headers and data. N-dimensional images. Standard header cards. WCS.
  • FITS tables
  • Extensions/HDUs
  • Routines: Fortran/C cfitsio, Python astropy.io, IDL Users library FITS routines, e.g., mrdfits/mwrfits

• note Python astropy.table unified I/O for multiple file types, including ASCII and FITS!

• Databases as alternative to data files

Python4astronomers primer on reading and writing files

Program organization: subroutines and functions

• Utility of functions:
  • improve readability of code
  • minimize/eliminate code repetition: more compact code and easier to change
  • use same functions in multiple programs

• Syntax of functions:
  • Fortran: subroutines (don't return a value, but can modify arguments) and functions (return a value, also can modify arguments (but see INTENT)!)

    FUNCTION ADD(a,b)

    REAL :: a,b

    ADD=A+B

    END

    PROGRAM MAIN

    IMPLICIT NONE
    REAL :: a=2, b=3, add

    PRINT *, ADD(a,b)

    END


  • C: functions return or don't return value depending on function type (void or other)

    float add(a,b) {
      return(a+b);
    }
    #include <stdio.h>
    int main() {
      float a=2.,b=3.;
      printf("%f\n",add(a,b));
    }


  • Python: function return values if return statement is given, and can return more than one! Positional and keyword arguments, default argument values.

    def add(a,b) :
       return(a+b)

    add(2,3)

    def div(a=1,b=1) :
       return(a/b)

    div(2,3)
    div(3,2)
    div()
    div(a=3)
    div(b=3)


    Another common default might be something like:

    def func(arg=None) :
       if arg is None :
          {do something}
       else :
          {do something else}


  • IDL: procedures (don't return a value) and functions (return a value). Note that IDL procedures and functions can't be entered interactively: need to enter in program, the compile program (.com nam), then execute using program name: procedure take arguments after commas, function arguments in parentheses. Optional/keyword arguments are allowed, but arguments are either positional OR by keyword.

    function add(a,b)
    return,a+b
    end

    add(2,3)


• global and local variables
  • local variables: variables defined inside of functions are only visible inside the function
  • variables outside of a function may be visible automatically inside the function, depending on language, or can be declared as global variables (FORTRAN modules or (old) common blocks), C global variables (and extern), Python global statement inside functions, IDL common

• are argument variables changed inside of procedures/functions?
  • Passing by value vs passing by reference vs pass by object reference
    • Passing by value essentially means that the subroutine creates a new variable that gets assigned the value of variable that was passed; the value of the variable in the main program can't get changed
    • Passing by reference means that the subroutine gets passed the address of the variable in the main routine, i.e. a pointer to the main routine variable. In this case, if the value that is pointed to is changed in the routine, it will be changed in the calling program!
    • Passing by object reference means that the subroutine gets passes a copy of the address of the variable in the main routine. If this address gets modified (i.e. the pointer is not modified), the value will be modified in the main routine, but if the copy of the pointer get assigned a new value, then any subsequent modifications to the value at the new address will not lead to any changes at the original address.
  • In simplest forms, C passes by value (but you can explicitly pass an address which is seen in the function as a pointer), Fortran passes by reference, Python by object reference (passes copy of pointer), and IDL by reference (but not for array or structure elements!)

• Using libraries in Fortran, C, Python, IDL.
  • In many cases, you may have functions that you wish to use with multiple main programs. In this case, rather than including the same code in multiple program files, you want to keep the code in separate ``utility" files, where these files contain only functions/subroutines, but not main programs.
  • Fortran and C: linking multiple object files. If the utility routines themselves compose of many files, multiple object files can be stored together in an object archive (.a files, using the ar command). If these files are centrally located they can be linked using the -lname option on the link command, in which case the linker will look for a file name libname in standard locations, which can be modified using the LD_LIBRARY_PATH environment variable. Linking with object archives includes the executable code from the archive (at least, the routines that are used by the program); this duplication of executable code can be avoided using shareable executables (but this is beyond where most users go).
  • Python: modules. from and import statements. Location of files: system installation and PYTHONPATH environment variable.
    • import name
    • import name.subdir
    • import name.subdir as subdir
    • from name import subdir
    • from name import *
  • PYTHON suggestion: collect all of your Python routines under a python directory and include this in your PYTHONPATH, so you can find all of your Python routines in one place (no need for ``I know I did this somewhere, but can't find where ...")
  • IDL: file naming (procedures should live individual in files named the same as the procedure name to be found) and IDLPATH for setting where IDL looks for procedures. Compiling vs. running

• Examples of some libraries:
  • Fortran: LAPACK (linear algebra), PGPLOT (plotting routines)
  • C: LAPACK (linear algebra), PGPLOT (plotting routines)
  • Python: standard libraries, including os (operating system routines), add-on libraries, e.g., astropy (astronomy-related routines, including I/O, numpy (numerical, including arrays), scipy (wide range of scientific/numerical techniques, many others
  • IDL: the Astronomy Users library, Markwardt library (esp, curve fitting), Buie library

Objects and object oriented programming

• traditional programs tend to think of variables and functions that act on variables. Object oriented program tends to think of objects that can have associated attributes, but also actions that may depend on the attributes

• Compare dictionary (or structured array) with a class

• objects: attributes and methods.

• Python:
  • everything is an object! E.g., strings files as objects

  • Inspecting attributes and methods in Python using iPython: object.<tab>, object.function?. Regular Python: dir() function.

  • Defining objects with CLASS, e.g.,

    h0 = 72.

    class gal :
        def __init__(self) :
            self.name = 'test'
            self.ra = 120.
            self.dec = 40.
            self.vrad = 3000.

        def dist(self):
            return self.vrad / h0


  • Note that object inheritance is possible, example: isochrone as a collection of stars

Error handling and code testing

• error handling: good code will trap errors and report the source rather than rely on the error message when the code crashes. Note Python try/except statements.

• testing code: find a case where you know the solution and make sure your code gets the right answer! Think of challenging cases that you can test, or at least test for behavior in the expected direction.

Debugging code

IDL: IDLDE

Python: pdb

C: ECLIPSE

Coding practices:

• style, e.g. PEP8 guidelines, e.g., white space, indentation rules, ...

• Make your program readable. Consider white space judiciously, recognizing tradeoff between separating program blocks and increasing length of code. Modular code is generally easier to read and digest.

• comments: every program must be commmented! Include an overview comment at the top and clarification comments throughout the code as needed. Don't need to comment what is apparent from reading the code if the code is straightforward. Separate comment statements are usually preferable to ``end-of-line" comments.

• documentation and documentation tools: Sphinx, doxygen (examples)

• Avoid hard-wired directories: consider use of environment variables to specify root directories

• Avoid hard-wired constants, file lengths

• version control and package management: tagging in version control software; modules: handles environment variable setup, dependencies, etc. Example...

More advanced coding

• Command line arguments

• Signal trapping

• sockets

• Parallel programming

• cross-language programming

Case study /review

• Consider isochrone reading code examples (isochrones.py)

• Example of astropy FITS I/O.
